Corona Nip Roll

Description of Corona Nip Roll
Corona Nip Roll used in pull roll stand of various polyfilm production lines, the corona nip roll works together with the corona roll and pull roll stand cooling roll. Corona nip roll surface coated synthetic rubber or EPDM rubber with good resilience and excellent ozone resistance, anti-static and aging resistant performance, and its roll surface can be machined into the crowing in different values by the numerical control crowned machine as required. The hardness of the synthetic rubber or EPDM generally 55-65 Shore A, after formula processing, the ruber can withstand temperatures up to 130 degrees Celsius.

Corona Nip Roll Specifications
(1). Corona nip roll construction: Single shell construction.
(2). Corona nip roll surface treatment: EPDM, Hypalon rubber covered.
(3). Corona nip roll surface hardness: 50-70 Shore A.
(4). Corona nip roll performance: Solvent resistance, aging resistance.

Corona Nip Roll Advantages
(1). Good stability under pressure at elevated temperature.
(2). Good abrasion and tear resistance.
(3). Very good resistance to acid and alkaline products and to ozone.
(4). Moderate resistance to polar solvents - not suited for contact with aromatic solvents - moderate oil resistance.
(5). Good consistent speed, the primary corona nip roll in the polyfilm production process ensure a consistent speed, which directly affects film quality and profitability.
(6). Good film quality, the flat and smooth surface of the corona nip roll prevents defects such as creasing or film damage caused by crushing the folds.
(7). Uniform pressure, the corona nip rollers apply uniform pressure across the film, ensuring consistent and equal roll speed and uniform pressure between the rolls.
