Slitter Grooved Roll

Description of Slitter Grooved Roll
Slitter grooved roll ‌ is a key component that is primarily used for precise slitting of films during the slitting process. The design and function of the slitter groove roll are crucial for improving the efficiency of high slitting and product quality.

The surface of the slitter groove roll is covered with regular grooves. In high-speed slitting machines, the main function of the slitter groove roll is to precisely slit films. As the film material passes through the slitter grooved roll, the blade falls into the groove and slit the film longitudinally, ensuring slitting accuracy and efficiency.

This design can effectively reduce the drift phenomenon of materials during the slitting process, and is particularly suitable for slitting films such as BOPP and BOPET.

Slitter Grooved Roll Specifications
(1). Maximum length: 13000mm
(2). Maximum diameter: 2000mm
(3). Maximum speed: 2000m/min
(4). Application: Used in high speed slitter machine
(5). Slitter grooved roll can be manufactured according to user's drawings.
